Metal Detector

Product Introduction: An electromagnetic induction device for detecting iron parts of conveying belt material
Adapt to Belt Width: 500~1400mm
Product Improvement: Voice and light alarm function

CONSULT
Leave Message
Email

Advantages

Digital phase shifter and detection technology
Stable performance
High detection sensitivity
Strong anti- interference ability
Low cost
Convenient operation and maintenance
Long service life

Work Principle

It uses the changing signal that produced when the metal enter into the sensor electromagnetic field, and through electronic technology to process and drive an actuator (electromagnet, motor switch) in order to remove harmful metals.

Application

Metal Detector is suitable for food processing, plastics recycling, crushing (coal / fossil power plant / mining / cement / mining / mineral processing), glass ceramics, chemical, rubber production, paper, tobacco, wood and paper material processing industry

Technical Parameters

Model	JTQ-500	JTQ -650	JTQ -800	JTQ -1000	JTQ -1200	JTQ -1400
Suitable for Belt Width (mm)	500	650	800	1000	1200	1400
Long Shaft with Inner Bore (mm)	700	850	950	1150	1370	1590
Short Shaft with Inner Bore (mm)	330	330	370	410	510	610
Max. Sensitivity for Normal Ore (mm)	20 ~25	25 ~30	25 ~30	35 ~40	45 ~50	55 ~60
Max. Sensitivity for Magnetic Ore (mm)	30	35	40	50	60	70
